Indoor 8 Core Bulk Fiber Optic Cable Single Mode PVC LSZH USE Indoor
Bulk Fiber Optic Cable Construction
| Number of fiber | 8core |
| Loose tube | material | PBT |
| diameter | 2.2 ( outer / inner ) |
| Tube - filling | Tube filling compoun |
| Steel wire | size | 0.8mm |
| Number | 2 |
| Outer sheath | material | PE, HDPE, LDPE |
| diameter | 1.8 ± 0.2mm |
Bulk Fiber Optic Cable Mechanical Characteristic
| Core | Cable diameter | weight |
| 1~8 | 8.0mm + / - 0.3mm | 65kg / km + / - 10kg |
| Temperature range | -40 ~ +70 ( ℃ ) | ----- |
| Min Bending Radius(mm) | Long term | 10D |
Min Bending
Radius(mm) | Short term | 20D |
Min allowable
Tensile Strength(N) | Long term | 1200 |
Min allowable
Tensile Strength(N) | Short term | 1500 |
| Operation temperature | -40 ~ +70 ( ℃ ) |
| Installation temperature | -20 ~ +60 ( ℃ ) |
| Storage temprature | -40 ~ +70 ( ℃ ) |
Bulk Fiber Optic Cable Features
1. Tight buffer fiber ease of stripping.
2. The jacket anti-corrosion, anti-water, anti-alltraviolet ratardation, flame retardant and harmless to environment etc;
3. Excellent flame retardart jacke and anti-torsion;
4. Soft, flexible, easy to splice, and with big capacity data transmission;
5. Excellent performance of anti-torsion;
6. All dielectric structure protect it from electromagnetic influence;
Bulk Fiber Optic Cable Application
1. Multi optical fiber jumper, patch cord, pigtail cable;
2. Indoor any purpose cable distribution
3. Backbone building distribution cabling.
4. Installation: wall, interlayer, pipe, trough, duct.
Bulk Fiber Optic Cable Specification
| Fiber count | Cable Diameter (mm) | Cable Weight (kg/km) | Tensile (N) Long/ Short term | Crush (N/100mm) Long/ Short term | Min. Bend Radius (mm) Dynamic/ Static |
| 4 | 5.0 | 19.0 | 130/440 | 200/1000 | 20D/10D |
| 6 | 5.2 | 23.0 | 130/440 | 200/1000 |
| 8 | 5.5 | 26.0 | 130/440 | 200/1000 |
| 12 | 6.5 | 36.5 | 200/660 | 200/1000 |
| 16 | 7.5 | 44.5 | 200/660 | 200/1000 |
| 24 | 8.2 | 54.5 | 200/660 | 200/1000 |
| Note: 1. The min. bend radius (static) is 5D when G657 fiber is used. 2. Range of temperature: -40 ~ +70 °C 3. D is outer diameter of the round cable 4. Tight-buffered fiber is 0.9mm |
